GS-SZ252 High Efficiency Cheap Double System 6G 12G Flat Jacquard Sweater Knitting Machine
Double systems single carriage, the carriage servo high-speed rotation max time 0.05 seconds. 5.2inch carriage length is reduced by 40mm, that greatly improving efficiency. lt is a multi-purposemachine.which can knit from 7G to 3.5G fabrics. The steel wire comb can save the time of knittingwaste yarn. With scissor clips , knitting pieces can fall down one by one, no need taking away ofwaste yarn. The operator can handle more machines. And it also can save the cost of waste yarn.In short, the advantages of zero finishing comb are: saving time, saving labor, saving cost, reducingthe labor intensity of workers.
Real time position state detection by motor control is more stable
|
MODEL |
GS-SZ252 |
|
GAUGE |
3G,3.5G,3-5-7G,5G,6G,7G,8G,9G,10G,12G,13G,14G,15G |
|
KNITTING SYSTEM |
DOUBLE SYSTEM SINGLE CARRIAGE |
|
KNITTING WIDTH |
52（INCH） |
|
KNITTING SPEED |
MAX.1.4M/SEC |
|
KNITTING FUNCTION |
TRANFER、TUCK、MISS、JACQUARD、INTARSIA、HIDE OR APPARENT SHAPING. |
|
STITCH DENSITY |
STITCH SYSTEM CONTROLLED BY STEPPING MOTOR,128 SECTION STITCH SELECTABLE, ADJUSTABLE SCOPE SUPPORTED BY SUBDIVISION TECHNOLOGY:0-650 |
|
RACKING |
CONTROLLED BY AC SERVO MOTOR,RACKING WITHIN 2 INCHES AND WITH FINE ADJUSTIING FUNCTION. |
|
DRIVE SYSTEM |
SYNCHRONOUS BELT DRIVE,AC SERVO SYSTEM |
|
NEEDLE SELECTION |
CONTROLLED BY COMPUTER,ELECTRIC MAGNET NEEDLE CHOOSE SYSTEM WITH HIGH EFFICIENCY. |
|
COMB DEVICE |
CHOOSE CLOSE U TYPE COMPOSE NEEDLE HOOK,THIS SPECIAL COMPOSE HOOK RELIABLE TO PICK UP YARN OR RELEASE,BEAD UNSEATING. |
|
SCISSOR AND CLAMP |
INCLUDING 2 SCISSOR AND 4 CLAMPS ,WHICH INDIVIDUALLY CONTROLLED BY 6 MOTORS SEPARATELY, LOCATED THE BOTH OF NEEDLE BED SEPARATELY, FURTHER TO INCREASE THE WORK EFFICIENCY AND TO REDUCE YARN CONSUMPTION. |
|
YARN CARRIER |
2x8YARN CARRIERS ON EACH SIDE OF 4 GUIDE RAILS,SHIFTABLE ON ANY NEEDLE POSITION |
|
TAKE DOWN ROLLER |
PROGRAMMED INSTRUCTION CONTROLLED BY STEPPING MOTOR,128 SECTION LEVELS SELECTION ADJUSTABLE AREA:0-100 |
|
NO WASTE YARN COMB |
NO WASTE YARN COMB,WITOUT WASTE YARN,DIRECTLY LIFTING THE COMB SAVES TIME FOR KNITTING WASTE YARN. WHEN COMBINED WITH SCISSORS AND CLIPS,SINGLE PIECES CAN BE DROPPED WITHOUT THE NEED FOR WASTE YARN, HELPING WORKERS TO SAVE TIME AND SAVING YARN COST. |
|
SINKER SYSTEM |
ASSIST KNITTING,HAVE VARIOUS RESULTS OF SHAPING AND STOP. |
|
PROTECTION SYSTEM |
THE MACHINE WILL AUTOMATICALLY ALARM IF YARN BREAKING,FLOAT YARN,REWIND,END OF KNITTING,FAIL OF RACKING, NEEDLE BREAKAGE,SAFETY SENSOR AND ERROR PROGRAMMING OCCUR ECT. |
|
CONTROL SYSTEM |
1、ADOPT LCD SCREEN,INPUT DEVICE:USB,SYSTEM MEMORY 256MB,A GREAT AMOUNT OF DESIGN FILES CAN BE STORED. 2、MONITORING MENU,EACH KIND OF OPERATING PARAMETER,CAN BE SHOWN, AND THEY CAN BE ADJUSTED AT ANY TIME WHEN THE MACHINE IS RUNNING. 3、DESIGN SYSTEM IS VISUAL AND EASY TO UNDERSTAND AND UPGRAD. 4、MULTI LANGUAGE VERSION,THERE ARE CHINESE,ENGLISH ETC. |
Q:Supplier profile
A:We’re the manufacturer of flat knitting machine since 1992,with more than 100 technicians in after-sale service team,have served
customers in more than 40 countries.
Q:Product introduction
A:The machine is suitable for collar,sweater,shoe upper,hat,scarf,rib...textile production.Just design pattern by software in the
computer,and input pattern to machine by USB,you can knit anything you need.
Q:Machine warranty
A:One year.For any spare part,the customer can purchase from us for life.
Q:Delivery time
A:Normally 15 days after deposit.If the machine you need is in stock,we can ship it shortly.
Q:Machine package
A:The inner layer is plastic packaging to avoid dust;the middle layer is vacuum packaging to avoid moisture and rust during sea
shipping;outside is wooden package and iron under frame to protect machine during transportation.
Q:More question
A:Please feel free to contact Summer via +86 15995930942 or summer@guoshengchina.cn
